900mm-2200mm ISO9001 Approved Huatao Shaftless Mill Electric Roll Paper Reel Stand Hot

Basic Info

Model NO.	mill roll stand
Driven Type	Hydraulic
After-Sales Service Provided	Engineers Available to Service Machinery Overseas
Automatic Grade	Automatic
Width Min	900mm
Main Shaft Dia	242mm
Width: Max	2200mm
Working Pressure(MPa)	16-18MPa
Transport Package	Wooden Box
Specification	900mm-2200mm
Trademark	Huatao
Origin	China
HS Code	8401200000
Production Capacity	25 Sets Per Month

Product Description

Reel paper Mill Roll Stand special used for Cardboard corrugated production mills, Sometimes also used for kraft paper rewinder for supporting the paper jumbo rolls with stability speed.

Detailed Photos

Product Parameters

Mill Roll Stand Parameters
Maximum Paper Roll Diameter	φ1500mm
Effective Width	900mm-2200mm
Maximum Support Weight	3t
Main Axis	φ242mm
Pneumatic Source Pressure(Mpa)	0.4---0.8Mpa
Magnetic Valve Voltage	380V 50HZ
Working Pressure(Mpa)	16-18mpa
Mill Roll Stand Characteristics
The Structure is Double Rotary Shafts with Four Arms
Support Two Paper Mill Rolls on both Arms at the Same Time
Hydraulic Control for Paper Mill Roller Up-down, Clamp-open, and Centering
Web Tension Controlled by Pneumatic Brake or Manual Brake
Tapered Center, Stretch Center, and Springiness Chucks are Optional

Packaging & Shipping

Our Advantages

1. Your inquiry related to our product & price will be replied to within 24 hours.

2. Rich experience in packaging machinery parts.

3. Bulk purchase quantities

4. Share the competitive prices with customers.

5. Good quality control and after-sale support.

6. Guaranteed delivery time.

FAQ

1.
Q: Why choose Huatao?1). 22 Years of Specialization in Paper & Corrugated cardboard2). Over 2000 successful experiences on the corrugated cardboard production line3). Strict inspection before delivery4). We have a series of none crush wheels to meet different corrugator lines.2.
Q: How about the after-sale service?All-round after-sales Service SystemAlways online 24 hours. for Email, Whatsapp.
